															Quadrant Bollard
QUADRANT  BOLLARD — series stands out as a dependable option for pathways, landscaped areas, and various public spaces, featuring a square frame, complementary column choices, and a four-way light distribution.
-Glare is effectively minimized through a concealed light source.
-The 4 way light distribution not only efficiently illuminates pathways and areas but also introduces a distinctive visual effect.
-Various height options and a coordinating column make it suitable for high-end architectural projects.
-Its minimalistic design ensures seamless integration with diverse architectural styles.
-The bollard is characterized by easy installation and maintenance.
Technical Data

															| PHYSICAL | |
| Body | Aluminium Extruded Profile |
| Finish | Polyester Powder Coated |
| OPTICAL | |
| Diffuser | Opal Polycarbonate |
| Light Emission | Indirect Light Distribution |
| ELECTRICAL | |
| Light source | LED |
| CRI | >80 |
| CCT | 3000K-4000K-5000K |
| Driver | Electronic Included |
| 220-240 VAC Non-Dimmable Driver | |
| 1-10V or DALI available on request | |
| Operating Temperature | -40°C ~ +50°C |
| Humidity | 10% ~ 90%RH |
Technical Drawing
